Acta Cryst. (2007). E63, m2184  [ doi:10.1107/S1600536807034678 ]

(2,2'-Dicarboxy-4,4'-carbonyldibenzoato)bis(1,10-phenanthroline)copper(II) dihydrate

L.-J. Hao and T.-L. Yu

Abstract: In the title compound, [Cu(C₁₇H₈O₉)(C₁₂H₈N₂)₂]·2H₂O, the Cu^II cation is hexacoordinated by two carboxylate O atoms from one of the two deprotonated carboxyl groups in the 3,3,4,4-benzophenone tetracarboxylate, and four N atoms from two 1,10-phenanthrolines, showing a slightly distorted octahedral geometry. A network of hydrogen bonds links the units into a three-dimensional structure.

Online 20 July 2007

Copyright © International Union of Crystallography
