Acta Crystallographica Section E

Structure Reports Online

Volume 68, Part 12 (December 2012)


organic compounds



pv2596 scheme

Acta Cryst. (2012). E68, o3290-o3291    [ doi:10.1107/S1600536812044479 ]

11-Hydroxy-9-[1-(4-methylphenyl)-4-oxo-3-phenylazetidin-2-yl]-18-oxo-10-oxa-2-azapentacyclo[9.7.0.01,8.02,6.012,17]octadeca-12,14,16-triene-8-carbonitrile

S. Suhitha, T. Srinivasan, R. Rajesh, R. Raghunathan and D. Velmurugan

Abstract: In the title compound, C33H29N3O5, the four-membered ring of the [beta]-lactam fragment is essentially planar (r.m.s. deviation = 0.0122 Å), with the carbonyl O atom displaced from this ring by 0.856 (9) Å. The mean planes of the methoxyphenyl and phenyl rings are inclined at dihedral angles 85.10 (7) and 21.56 (14)°, respectively, with respect to the mean plane of the four-membered ring. The pyrrolidine rings adopt envelope conformations with C atoms lying 0.535 (4) and 0.519 (4) Å out of the planes formed by the remaining ring atoms. The furan ring also adopts an envelope conformation with a C atom 0.560 (3) Å out of the plane formed by the remaining ring atoms. The nine-membered indene ring is almost planar (r.m.s. deviation = 0.0240 Å), with the carbonyl O atom displaced by 0.145 (3) Å from this ring. The molecular structure is stabilized by a strong intramolecular O-H...N hydrogen bond and the crystal structure is consolidated by C-H...O hydrogen bonds.


htmldisplay filedownload file

Hyper-Text Markup Language (HTML) file
[ doi:10.1107/S1600536812044479/pv2596sup0.html ]
Supplementary materials


cmldisplay filedownload file

Chemical Markup Language (CML) file (10.7 kbytes)
[ doi:10.1107/S1600536812044479/pv2596Isup3.cml ]
Supplementary material
