Figure 3
Top: schematic arrangement of the most important components that constitute the experimental setup at the nanofocus endstation (MS = microscope, XRF = X-ray fluorescence detector). Owing to their small size, the positions of the waveguide and of the sample are only indicated with arrows. Bottom: photograph of the current setup at the nanofocus endstation of the MINAXS beamline. The size of the granite table is 2.5 × 0.8 m. The beam direction is from right to left and the detector is removed for a better visibility of the setup.
