Figure 4
SEM images, (a) and (b), of the MER MWCNTs functionalized similarly to previous work (Baek et al., 2004BB1) and used in the composites. The diameters of the nanotubes after functionalization are ~800 Å, which validates the dimensions obtained from USAXS using the STFF and the fractal-tube form factor.
