Figure 6
Electron channeling contrast micrograph of a grain containing double twins including twin set_1 and twin set_2. The two twin sets crisscross the width of the grain. The width of the twins ranged between 300 and 700 nm in this particular grain. The compression direction is aligned parallel to the vertical direction in the micrograph.
