Figure 9
Average background subtraction filtered HR-TEM image and corresponding FFT of the area located at the corner of the trench. The observed extended defects appear as straight lines of variable length parallel to the [[1\overline{1}00]] direction and correspond to dislocations extended in the (0001) planes.
