Figure 7
Schematic representations of crystallographic plane symmetries relevant to XRD reflections in cubic crystals, illustrated using stereographic projections: (a) [111]-oriented and (b) [110]-oriented configurations. Planes exhibiting threefold and sixfold rotational symmetry are highlighted in blue and red, respectively.
