Figure 8
Zoomed views of the frog head subregions. Rows: regions A, B and C from Fig. 5[link]. Columns: the difference between the two methods (left); SLD + Paganin et al. (center); SLD + EPR with five spectral points (right). The used gray scales have a constant minimum to maximum width over a given row, and are centered, for each image, over the soft matter range.

Journal logoJOURNAL OF
SYNCHROTRON
RADIATION
ISSN: 1600-5775
Volume 32| Part 5| September 2025| Pages 1291-1301
https://doi.org/10.1107/S1600577525005223
