Figure 2
Energy-dependent changes in (a) Rsplit and (b) CC1/2 based on datasets comprising 12000 integrated images. The grey, red, blue, green and purple lines represent data collected at 12.4, 17.5, 20, 23 and 25 keV, respectively. The plot regions highlighted in yellow are enlarged in the insets. Wilson plots of these datasets are shown in Fig. S1 of the supporting information.

Journal logoJOURNAL OF
SYNCHROTRON
RADIATION
ISSN: 1600-5775
Volume 33| Part 2| March 2026| Pages 344-350
https://doi.org/10.1107/S1600577525011063
