Figure 2
Simplified imaging principle, illustrating visible-light generation from X-ray interactions and optical path redirection via reflective components. Representative HEPS implementations include monochromatic microbeam imaging with a 20 mm-diameter YAG:Ce scintillator and switchable magnification, as well as large-field imaging using a 65 mm × 30 mm diamond target and a mirror-assisted optical path.
