Figure 1
Experimental setup: (a) image at sample position of the 1 mm × 3 mm unslitted monochromatic X-ray beam at 5980 eV; (b) picture of the setup, high angle view; (c) picture of setup, profile angle view; (d) setup in model space, profile view – the sensor position inside the detector is indicated by an arrow; (e) schematic representation of the setup, top view. The beam path of the collected X-rays fluorescence is represented in pale green.
