Figure 3
(a) Three-dimensional (3D) schematic model of the reaction cell showing key components: (1) gas inlet; (2) gas outlet; (3) thermocouple, positioned to monitor the temperature accurately; (4) resistive coils, heating to desired reaction temperatures; (5) capillary, allowing access for in situ measurements in continuous gas flow conditions; and (6) metal gasket face seal fittings, ensuring a hermetic and high-pressure-resistant seal. (b) Photograph of the assembled reaction cell, illustrating the physical arrangement, corresponding directly to the 3D model in (a).
