Figure 9
(a) Schematic side view of the LAMINO-II station highlighting the positioning modules for sample, detector and optical elements. (b) Photograph of the sample manipulator comprising a large air-bearing rotation axis (1) with open aperture in its centre, an x–y cross-table (2), as well as a cable drag (3) and a sample altogether tilted to an angle typical for lamino­graphic measurements of a sample (4).
