Figure 10
(a) Vertical displacement Uy along the beam footprint centre axis over FWHM length and second order polynomial fit at 1 µs after XFEL pulse; (b) the higher order deformation residual, i.e. the difference between fit and FEA results for the case of either water or LN2 and repetition time tper = 10 µs.
