![[Figure 2]](ing5026fig2mag.jpg)
|
|
Figure 2
(a) The upper photograph illustrates a windowless camera mounted exactly at the sample position. The lower image shows overlaps of laser and X-rays monitored by the camera. (b) The upper photograph illustrates a windowless fast photodiode mounted exactly at the sample position. The lower figure shows a two-pulse signal that represents the laser and X-ray pulses measured by the fast photodiode. (c) Position of the mounted liquid flat-sheet jet at the same position as the previously mounted camera and diode. The top image shows a larger view; the bottom shows a zoomed-in view of the blue oval line with the excitation laser on the jet. The blue line is a guide for the eye showing the border of the liquid and the nozzle housing. |
![[Figure 2]](ing5026fig2.jpg)
